Building Automation System

EC-Net™ Web-based Multi-protocol Building Automation and Energy Management Platform

Overview

Distech Controls' building automation system (BAS) multi-protocol, multi-function capabilities provide seamless and intelligent integration of HVAC, Lighting, Access Control, CCTV, Energy Management, and other building systems.

Our BAS provides the power to do more, with cost-effective and scalable integration of all your control, monitoring, and operational needs. A truly open solution, the platform creates a sustainable foundation that supports and evolves with your building system’s lifecycle.

  • checkmark

    Program, manage, and monitor your building automation system using a Web browser

  • checkmark

    Monitor, acknowledge, and review alarms with sophisticated alarm processing and routing, including e-mail and paging

  • checkmark

    Choose best-of-breed products and prolong the useful life of existing systems by extending their capabilities, regardless of manufacturer or protocol

  • checkmark

    Open standards provide a useful, cost-effective infrastructure for convergence with IT networks

  • checkmark

    Common platform provides global functions such as network control, monitoring, alarming, database and log management, and audit trails for all building functions

  • checkmark

    Manage multi-site or campuses with one system

  • checkmark

    Leverage real-time business intelligence through connectivity with enterprise applications such as accounting, tenant billing, and energy management and utility monitoring interfaces

Download Our Brochure

Download our brochure to learn how Distech Controls' EC-Net building management solution provides the power to do more, with cost-effective and scalable integration of all your control, monitoring, and operational needs.
Download

Network and Interface

The EC-Net building management system (BMS) is a comprehensive Web-based platform powered by the Niagara Framework®.

DIS_8967_Distech Web Images_0219-Image001

The open structure of EC-Net building management system (BMS) creates a common development and management environment for the integration of BACnet®, LONWORKS®, Modbus™, and other standards.

More than a building management system, EC-Net system provides all the tools you need to gain intelligence into your buildings’ performance and arm you with the ability to rapidly react to any situation that may adversely affect energy costs, business performance, and ultimately, your bottom line.

  • Products and Models

    • DIS_8967_Distech Web Images_0219-Image003

      EC-Net 4 Supervisor

      The EC-Net 4 Supervisor is a software platform used in server-class applications. It makes managing all buildings at an enterprise level possible, giving facilities managers the ability to quickly respond to problems and insights to optimize their system.

      VIEW DETAILS

    • DIS_8967_Distech Web Images_0219-Image002

      EC-Net 4 Alarm Console

      The EC-Net 4 Alarm Console is a flexible client application for monitoring alarms from EC-BOS or Supervisor nodes and provides an alternative way for users that do not require the full EC-Net 4 Pro to monitor, acknowledge and review current alarms within a building or campus.

      VIEW DETAILS


EC-BOS: Multi-protocol Web Building Controllers

The EC-BOS real-time control devices support a wide range of protocols including LONWORKS®, BACnet®, Modbus® and Internet standards. The EC-BOS devices connect to system field devices, such as LONWORKS or BACnet controllers, and provide real-time control functions. It combines integrated control, supervision, data logging, alarming, scheduling and network management functions with Internet connectivity and web serving capabilities in a small, compact platform.

Using the EC-Net platform, the EC-BOS controllers provide a fully distributed system when multiple units are networked together, are ideal for smaller facilities, remote sites, and for distributing control and monitoring throughout large facilities.

The EC-BOS control devices are part of the EC-Net web-based multi-protocol solution, designed to integrate a variety of devices and protocols into unified, distributed systems. EC-Net system supports a wide range of protocols including LONWORKS®, BACnet®, Modbus® and Internet standards.

  • Combines real-time integrated control, supervision, data logging, alarming, scheduling and network management functions with Internet connectivity and web serving capabilities
  • Web-access allowing the management of your building automation system in real-time over the Internet
  • Multi-protocol management - Integrate LONWORKS, BACnet and Modbus devices into one common system with uniform data presentation
  • BTL listed as BACnet Building Controller
  • Eliminates need for routers, gateways and BACnet master controllers Preserve existing system investments by extending its capabilities
  • Provide a fully distributed system when multiple units are networked together
  • Products and Models

    • EC-BOS-8_product

      EC-BOS-8

      With Internet connectivity and Web serving capability, the EC-BOS-8 controller provides integrated control, supervision, data logging, alarming, scheduling, and network management.

      Also, it allows integration of various field buses and communication protocols. The EC-BOS-8 controller operates with EC-Net 4 web-based building management platform.

      VIEW DETAILS

Interested in Getting More Information About Our Building Automation System?
